Notes from an Electroforming Workshop


3 Minute Read

HomeLearning CenterJewelry MakingNotes from an Electroforming Workshop
By F.R. NicholsMore from this author

These notes are from a workshop given by Maria Phillips at the Enamelist Society Conference in Olympia, WA in August 2003.

Necessary Items

Rectifier. Available at most jewelry supply outlets. The size will vary according to the size of your bath. In most cases, a small rectifier will be sufficient for the individual artist.

Tank. This is where you house your bath. It is important to have a pan of some sort underneath your tank (of sufficient size to accommodate the liquid should your tank leak). Since the bath is acid, all necessary precautions MUST be taken.

The size of the bath must correspond to the rectifier. You cannot have a huge bath and a small rectifier. The tank must be made of glass, polypropylene or polyethylene plastic. Plastic is preferred because there is less chance of breakage. You can get a plastic container from the plastic supplier in your community. A glass tank can be obtained from a fish or pet shop. Be aware of leakage. Fish tanks are put together with plates of glass and silicone. Remember, your bath will house acid, which could do serious damage if it leaks. Have your fish tank in another container that is acid proof in case the system leaks. Another possibility for a tank is a truck or automobile battery case. These plastic shells are designed to contain batteries and resist acid. They are easily and inexpensively obtained from auto parts stores.

Bus Bars. These are metal bars that support the anodes and cathodes. You will need anywhere from 2 to 3 bus bars, depending how many anodes you have. These bars should be metal and capable of conducting electricity. You may want to use a non-corrosive material. She uses copper .25 round stock and flattens one end of it so that the alligator clips have more surface area on which to attach. The bars need to be sturdy enough to support both your work and the anodes.

Filtration System. You need a filtration system. These must be bought through the industry and are expensive. The filtration system helps maintain the chemical balance of the bath and promotes circulation, which assists in plating and filter out surface debris. Because the bath is acid, it will attack and degrade a common store-bought filter. This would contaminate your bath. The carbon that is a part of most common filters will deplete your bath of any organic substance, including your brighteners. You will have to replenish them if you choose this type of filter. Organic materials affect the chemical makeup of your bath quicker over time than wax or plastic materials. You may need to consider filtering your bath every four to six months, depending on how much you are using it. Once you have filtered it, you will need to replenish the brighteners.

Note: You are working with hazardous materials. They must all be neutralized and disposed of properly at a hazardous waste location in your city. This includes the filter, which must also be neutralized before disposal in the proper site.

Agitation System. This system provides a constant source of circulation while you are running your bath. You need to find an air pump that is of sufficient size for your bath. A low cost system can be purchased at the fish supply store. You can create an agitation system out of PVC tubing and a fish tank air system. If you use PVC tubing, drill holes in it to provide circulation.

Heater. The bath needs to be kept at a temperature of 75° - 80°F. Heat assists the chemical process. A simple glass fish tank heater will work. Make sure you buy one that is capable of heating your size tank and that any plastic parts of the heater cannot be submerged in your bath, because acids will dissolve plastic and contaminate your bath.

Anodes. Phosphorized copper must be obtained from a distributor, specifically a plating company. Anodes should be 1.5 to 2.5 times the cathode area/size.

Titanium Hooks. They are used to suspend the anodes and are non-corrosive.

Anode Bags. These should be napped polypropylene or dynel. They assist in filtration, plating and containing the phosphorous layer/deposit that the anodes shed during the plating process.

Making the Bath Solution

What You Will Need:For 20 Gal. BathFor 10 Gal. Bath
Liquid Copper Sulfate12 Gallons6 Gallons
Sulfuric Acid2400 ml or 2.41200ml
Hydrochloric Acid or Muriatic Acid12 ml6ml
Brighteners *300 ml150 ml
Distilled H2OApprox.. 5-7 gal.Approx. 1-3 gal.



By F.R. Nichols [Volume 23, Number 2, April, 2004]
